Red Light Violation Detection System
The Red Light Violation Detection System is a system developed to prevent accidents caused by red light violations at signalized intersections and to detect violating vehicles.
With POINTR K3000;
Integrated license plate recognition unit
High resolution camera
Continuing to work by keeping records in memory in case of network connection failures
Night vision with IR Led
IP66, IK10 and NEMA 4x certified enclosure
24/7 uptime
Send data to a central server via FTP
Wide angle camera
High power flash
Virtual loop
Features
Lane-based red light violation detection
License plate recognition
24/7 red light violation detection
Remote access
Automatically stop the system in case of failure in signaling
24/7 Keeping it running
Ability to close the system from the center when the traffic police manage the intersection
High definition video recording
Automatic penalty receipt issuance
Violation detection is done by checking the color illuminated at the intersection by the intersection controller or the relevant signalizer and evaluating the information from the detectors. All these parameters are combined and verified to detect the violation and the resulting image is reported to the recording unit, thus eliminating the possibility of error.
The violation detection process is carried out with three consecutive photographs taken from the rear direction in such a way as to document and prove that the vehicle has committed the violation.
The red color of the traffic signalizer is prominently displayed in the violation picture.
For each violation, an adjustable parametric violation video is recorded at the desired length.
Uninterrupted video recording is taken by the system for 24 hours.
The moment of violation is captured in maximum 20 milliseconds.
In order for the violation pictures to have legal evidence value, the originality of the picture is guaranteed by digital signature method.
The breach detail photo is taken in high quality with 18 megapixel resolution so that all details of the breach can be clearly seen.
If desired, the camera resolution can be changed according to the displayed area.
Ability to take 8 frames per second photos at high resolution in the digital camera technology used.
Gige vision technology that can optionally take 15 frames per second in the camera used.
Ability to detect up to 6 lane violations with a single system.
Ability to detect all simultaneous violations without missing them.
